06Cr17Ni12Mo2
Stainless steel is an alloy of Iron with a minimum of 10.5% Chromium. Chromium produces a thin layer of oxide on the surface of the steel known as the passive layer. This prevents any further corrosion of the surface. Increasing the amount of Chromium gives an increased resistance to corrosion.
Product Description
Core Product Overview
316 Stainless Steel Plate (ASTM A240 / SUS316 / 06Cr17Ni12Mo2) is a premium molybdenum-bearing austenitic stainless steel sheet, widely recognized as the top choice for projects requiring exceptional resistance to chloride corrosion, acidic environments, and sustained high-temperature operation. Compared to standard 304 stainless steel, the 2.0–3.0% molybdenum content in 316 grade dramatically improves its anti-pitting, anti-crevice corrosion performance, making it far more reliable for harsh working conditions.
Our full stock range covers thin plates (0.1mm–3mm), medium plates (3mm–25mm), thick plates (25mm–100mm) and extra-thick plates over 100mm, with surface options including 2B, BA, 8K mirror, HL hairline, No.1 hot-rolled finish. Every batch is sourced from top domestic and international steel mills, with 100% material test report (MTR) provided before delivery.
Key Specifications & Standard Compliance
| Parameter | Detailed Data |
|---|---|
| Standard Grade | AISI 316, 316L, 316Ti, 316H, SUS316, 1.4401, 06Cr17Ni12Mo2 |
| Thickness Range | 0.01mm – 100mm (custom ultra-thin foil & extra-thick plate available) |
| Common Sheet Size | 1000x2000mm, 1219x2438mm (4ft x 8ft), 1500x6000mm, 1524x6096mm (5ft x 10ft) |
| Surface Treatment | 2B, BA, 6K/8K mirror, HL hairline, No.4 brushed, No.1 hot rolled, embossed, coated |
| Density | 7.98 g/cm³ |
| Mechanical Properties | Tensile Strength ≥ 620MPa, Yield Strength ≥ 310MPa, Elongation ≥ 30% |
| Compliance Standards | ASTM A240, ASTM A480, ASME SA240, EN 10088, GB/T 24511 |
Unmatched Performance Advantages
- Superior Chloride & Acid Corrosion Resistance
The added molybdenum element stabilizes the material’s passive film, delivering outstanding tolerance to seawater, salt spray, acetic acid, phosphoric acid, sulfate and alkaline solutions. It effectively avoids pitting corrosion even in coastal splash zones and high-salinity working environments. - Excellent High-Temperature Stability
316 stainless steel plate can continuously work at 1200–1300°C without structural deformation, maintaining stable mechanical strength and creep resistance under long-term high-heat conditions. The 316H variant further optimizes high-temperature performance for furnace and heat exchanger applications. - Anti-Intergranular Corrosion Design
Our 316Ti grade adds titanium element to preferentially combine with carbon, preventing chromium carbide precipitation at grain boundaries during 450–850°C sensitization heating or welding. This eliminates intergranular corrosion risks for welded pressure vessels and chemical reaction towers. - Outstanding Processability & Versatility
It features excellent cold forming performance, weldability and low-temperature toughness, no magnetic under solution treatment. You can easily carry out laser cutting, plasma cutting, bending, stamping, polishing and deep drawing without material cracking.
Wide Application Scenarios
Our 316 stainless steel plates are widely adopted in global industries, including:
- Marine & Offshore Engineering: Seawater desalination equipment, ship hull accessories, coastal facility supports, ocean platform auxiliary systems
- Chemical & Pharmaceutical Industry: Reaction tanks, heat exchangers, acid & alkali transport pipelines, pharmaceutical production equipment
- Food & Beverage Processing: Sterilization tanks, food conveyor systems, brewing equipment, kitchenware with strict hygiene requirements
- High-Temperature Industrial Fields: Boiler components, furnace linings, exhaust treatment equipment, aerospace structural parts
- Architectural & Decoration Projects: Coastal building curtain walls, anti-corrosion handrails, public facility decorative panels
Customization & Processing Services
We are not just a stainless steel plate supplier — we provide one-stop solutions to cut your total procurement cost:
- Non-standard thickness, width and length custom production according to your drawings
- Precision processing: Laser cutting, water jet cutting, slitting, edge trimming, 8K mirror polishing, wire drawing, titanium plating
- Small trial order support for new customers, large spot inventory for urgent delivery within 3 days
- Custom packaging for sea freight, anti-rust paper + wooden pallets to avoid transportation damage
Quality Assurance & Order Process
- Pre-production: Strict raw material inspection, all raw materials come from certified large steel mills
- In-production: Real-time thickness, flatness and surface quality monitoring during rolling
- Pre-delivery: 100% material composition spectrum test, mechanical property recheck, complete MTR documents provided
- After-sales: 12-month quality guarantee, quick response for any product quality disputes within 24 hours
Get Your Free Quote Today
If you are looking for a reliable 316 stainless steel plate supplier with stable quality, competitive price and fast delivery, we are your ideal choice.
- Leave your required thickness, size, quantity and application scenario in the inquiry form
- We will send you the formal quotation with detailed specification sheet and delivery plan within 2 working hours
- Free sample (thickness ≤3mm, 100x100mm) is available for your performance test, you only need to bear the express fee
